3.0mm Full-Set
Veterinary Endoscopic Imaging System
In addition to a 3.0mm standard endoscope, it also includes an all-in-one computer, a floor-standing storage stand, and image display software.
Clinical application subjects and scenarios
- Upper Gastrointestinal Tract (Upper GI): Observation, retrieval, brushing, or biopsy of the area from the esophagus to the stomach inlet.
- ENT and minor surgeries: nasal/nasopharyngeal surgery assistance; 1.2mm channel support instrumentation.
- Endoscopic-assisted sampling of urinary tract stones
- Emergency/Outpatient Management: Foreign Body Removal, Bleeding Assessment and Recording, Improving Process Efficiency and Safety
- Image communication/teaching: Photo/video archives facilitate communication with pet owners and case review.
Product Features
Working channel 1.2mm
It supports miniature instruments such as biopsy forceps, brushes, and retrieval hooks, enabling diagnosis and intervention to be completed in one go.
The front end is flexible (~270°).
The slender cavity can also be turned flexibly; the 60mm bendable length makes it easy to adhere to the wall and observe.
Dual bending control
Locked/Secondary deflection operation stabilizes the field of vision and improves handling efficiency.
Fully integrated system
15.6” panel, Windows 11, FHD display and recording; supports diverse I/O.
Technical Specifications
| Model Name | 3.0mm Full-Set Veterinary Endoscopic Imaging System |
|---|---|
| Model | VURS 700-01 |
| Working Length | 650mm |
| Deflection of Tip | 270 degree |
| Deflection Length | 60mm |
| Working Channel | 1.2mm(3.6Fr) |
| Outer Diameter | 3.0mm (9.0Fr) |
| Resolution | 700x700 pixels |
| Function | Locked deflection, Secondary deflection, image capture, video recording |
| Package includes | 1. One 3.0mm veterinary endoscope with working channel 2. All-in-One PC with integrated monitor 3. Fully-equipped endoscope stand 4. Imaging display software (pre-installed on PC) 5. One biopsy forceps (O.D. 1.0mm; 1200mm Length) 6. One straight-head cytology brush (O.D. 1.0mm; 1200mm Length) |
| Model Name | 3.0mm Full-Set Veterinary Endoscopic Imaging System-The screen |
|---|---|
| Model | VURS 700-01 |
| Size | 15.6" TFT LCD |
| Resolution | 1920x1080 pixels |
| OS Support | Windows 11 |
| External I/O Port | 4 * USB 3.2 Gen1 2 * USB 3.2 Gen 2 1 * HDMI 1 * LAN (RJ45, 2.5GbE Intel i226LM) 1 * Line-Out (3.5mm) 1 * Mic-In (3.5mm) 1 * Reset 1 * DC-In (5.5*2.5mm, Support 12~36VDC) 1 * Power Button |
Request a catalog/ Consult about a trial
Contact us for a complete catalog, clinical examples, and procurement options; we also provide support for clinical testing and educational training.
